The right wheel and tire combination can improve your skills and upgrade the performance of your E-bike on challenging off-road terrain. The new E-Deemax S is built specifically for E-bikes and has some unique technologies to help you ride smoother and have more fun on the trail.
Our patented PFP technology (Pinch Flat Protection) features rims with a wider contact surface at the top of sidewall to significantly reduce the risk of tire cuts and punctures. The 30mm wide rims allow you to run lower tire pressure for better traction and smooth rolling efficiency. Our patented Fore technology features a fully sealed upper rim bridge that eliminates the need for rim tape, making it the easiest system for mounting and changing tubeless tires.
ISM rim machining removes material from the rims in strategic areas to minimize weight without compromising strength, and our new Black Shield treatment protects the rims against impacts and scratches. We use 28 straight-pull spokes (same spoke length throughout) for a strong connection between the rim and hub, which has our ultra-reliable ID360 double ratchet system for quick engagement and acceleration. Set up for either 6-bolt or center lock disc mounts, these 29” wheels are available for Shimano HG9, XD and Micro Spline freewheel bodies and come with UST tubeless valves, spare spokes and accessories.
MAIN FEATURES
Significantly minimized risk of tire cuts and punctures
Thanks to its PFP (Pinch Flat Protection) rim sidewalls, this wheel is reinforced to endure the toughest obstacles.
Easiest tubeless system on the market
Fore technology: stronger rim profil thanks to less spoke holes,
Complete sealed rim and no rim tape for the best system on the market brought by the pionneers of tubeless.
Reinforced hub
Specially designed for the added torque of E-bike motors, validated for a total weight supported of 180 Kg.
SPECIFICATIONS
Weight
Weight Pair: 2010 g
Weight Front: 915 g
Weight Rear: 1095 g
Rims
Material: Maxtal
Height: 22 mm
Joint: SUP welding technology
Internal width: 30 mm
Drilling: Fore tapeless tubeless technology (front/rear 28 holes)
Braking: disc
Profile: asymmetrical
ETRTO size: 622x30TC hooked
Tire: UST Tubeless Ready
Spokes
Material: steel
Shape: straight, extra-flat, constricted, antirot (front)
Shape: straight, flat, antirot (rear)
Nipples: brass, black
Screw: M7
Lacing: crossed 3 (front and rear)
Hubs
Body material: aluminium
Body design: INFINITY
Disc standard: 6 Bolts or Center Lock®
Axle material: aluminum
Axle size: front 15x110 / rear 12x148
Freewheel technology: Instant Drive 360
Freewheel: -
Bearing technology: QRM automatic setting - sealed cartridge
Compatibility
Front axle adapters: 15x110 convertible to 9x110 (kit 99694101 sold separately)
Front axle adapters: convertible to 15x31mm with Torque Cap (kit V2374401 sold separately)
Rear axle adapters: 12x148 convertible to 9x141 (kit V2510801 sold separately)
Delivered with
User guide
UST valve not mounted on wheel
2 replacement spokes with each wheel
2 Multifonction adjustment wrench with the rear wheel
Intended use
Minimum tyre size: width 52mm - pressure max. 2.95Bar/43PSI
Maximum tyre size: width 76mm - pressure max. 2.45Bar/36PSI
ASTM category 5: gravity riding focused on the descent
Maximum weight supported by the wheels: must not exceed 180 Kg (bike weight included)
Data sheet
No customer reviews for the moment.
Rider using an E-MTB on demanding routes
Designed for riders using an E-Bike on demanding off-road terrain who need a robust wheelset, with aluminium rim and protection against cuts and punctures.
Rider who wants broad compatibility on a 29" E-bike
Suitable for those looking for a 29" wheelset compatible with E-bike, Shimano HG9, XD and Micro Spline, with 6-bolt or Center Lock standards.
Rider prioritising strength and rolling control
Recommended for those wanting a 2010 g wheel with 30 mm internal rim width, designed for traction, tyre protection and heavy-duty use.
Ideal
E-MTB rides on technical trails
The wheelset is designed for E-MTB and demanding off-road use, with a 30 mm rim and PFP protection against cuts and punctures.
E-MTB · Technical trails · 30 mm rim · Puncture protection
Very suitable
Installation on a 29" bike with disc brakes
The wheels are 29" and allow 6-bolt or Center Lock disc mounting, so they integrate with modern off-road setups.
29" · Disc brakes · 6-bolt · Center Lock
Very suitable
Use with Shimano HG9, XD and Micro Spline freehub bodies
Compatibility with Shimano HG9, XD and Micro Spline makes them suitable for multiple E-bike drivetrain configurations.
Shimano HG9 · XD · Micro Spline · E-bike
Suitable
Use with UST Ready tubeless
The fore tapeless tubeless system and the supplied UST valves facilitate use with UST Tubeless Ready tyres.
Tubeless Ready · UST · UST valves · Fore
Experienced E-MTB rider
Sport rider on demanding trails
It is designed for E-Bike use and demanding off-road riding. The specification also lists it for ASTM category 5, so it is suitable for gravity downhill riding.
It is set up for 6-bolt or Center Lock discs. This allows use with different disc brake systems.
It is compatible with Shimano HG9, XD and Micro Spline. This broadens fitting options across different E-bike drivetrains.
The main material is aluminium. The specification also lists Maxtal rims and an aluminium hub body.
The wheelset weight is 2010 g. This helps assess the wheelset as part of an E-bike setup.
The wheels are 29" with ETRTO size 622x30TC. This places them in the typical 29" E-MTB format.
